PEEK Tube Natural 1/16"OD x 0.0025"ID, Length 100 Feet
- Part Number:
- 1302002500-100F
- Product Type:
- Tubing
Frequently bought together:
Description
PEEK Tube Natural 1/16"OD X 0.0025"ID, Length 100 Feet
Features and benefits
- Excellent chemical resistance and inert to most commonly used solvents. Exceptions are very caustic reagents, strong acids and bases.
- Bio-inert and bio-compatible.
- Color coded to industry standards for easy identification of inner diameter.
- Leach free colorants.
- Smooth inner walls and precise IDs.
- Works well with either polymer fittings as well as stainless steel fittings.
- Can be formed to specific customer needs.
Recommended applications
LC, LCMS and automation solutions.
Product specifications
- Operating temperature up to 100°C max continuous use.
- Operating pressure range up to 10,000 psi (690 bar), size dependent.
- Can be used across a broad pH range of 2 to 14.
- Pre-cut lengths of 5', 10', 50' and 100'.
PEEK tubing tolerances and colors
| OD | ID | OD tolerance | ID tolerance | Max operating pressure | Color | |
| 1/16" | 0.0025" | ±0.001" | ±0.005" | 7,000 psi (483 bar) | Natural | ● |
| 1/16" | 0.004" | ±0.001" | ±0.005" | 7,000 psi (483 bar) | Black | ● |
| 1/16" | 0.005" | ±0.001" | ±0.001" | 7,000 psi (483 bar) | Red | ● |
| 1/16" | 0.007" | ±0.001" | ±0.001" | 7,000 psi (483 bar) | Yellow | ● |
| 1/16" | 0.010" | ±0.001" | ±0.001" | 7,000 psi (483 bar) | Blue | ● |
| 1/16" | 0.013" | ±0.001" | ±0.001" | 7,000 psi (483 bar) | Orange | ● |
| 1/16" | 0.015" | ±0.001" | ±0.001" | 7,000 psi (483 bar) | Natural | ● |
| 1/16" | 0.015" | ±0.001" | ±0.001" | 7,000 psi (483 bar) | Gray | ● |
| 1/16" | 0.020" | ±0.001" | ±0.001" | 6,000 psi (414 bar) | Orange | ● |
| 1/16" | 0.030" | ±0.001" | ±0.001" | 4,000 psi (414 bar) | Green | ● |
| 1/16" | 0.030" | ±0.001" | ±0.001" | 4,000 psi (276 bar) | Red | ● |
| 1/16" | 0.040" | ±0.001" | ±0.001" | 3,000 psi (207 bar) | Natural | ● |
| 1/32" | 0.0025" | ±0.0005" | ±0.0005" | 5,000 psi (345 bar) | Natural | ● |
| 1/32" | 0.004" | ±0.0005" | ±0.0005" | 5,000 psi (345 bar) | Black | ● |
| 1/32" | 0.005" | ±0.0005" | ±0.0005" | 5,000 psi (345 bar) | Red | ● |
| 1/32" | 0.007" | ±0.0005" | ±0.0005" | 5,000 psi (345 bar) | Yellow | ● |
| 1/32" | 0.010" | ±0.0005" | ±0.0005" | 5,000 psi (345 bar) | Blue | ● |
| 1/32" | 0.015" | ±0.0005" | ±0.0005" | 4,000 psi (276 bar) | Natural | ● |
| 1/32" | 0.015" | ±0.0005" | ±0.0005" | 4,000 psi (276 bar) | Gray | ● |
| 1/32" | 0.020" | ±0.0005" | ±0.0005" | 3,000 psi (207 bar) | Orange | ● |
| 360 µm | 50 µm (0.002") | ±0.0005" | ±0.0005" | 10,000 psi (690 bar) | Natural | ● |
| 360 µm | 75 µm (0.003") | ±0.0005" | ±0.0005" | 10,000 psi (690 bar) | Black | ● |
| 360 µm | 100 µm (0.004") | ±0.0005" | ±0.0005" | 10,000 psi (690 bar) | Red | ● |
| 360 µm | 125 µm (0.005") | ±0.0005" | ±0.0005" | 10,000 psi (690 bar) | Green | ● |
| 360 µm | 150 µm (0.006") | ±0.0005" | ±0.0005" | 10,000 psi (690 bar) | Yellow | ● |
| 1/8" | 0.062" | ±0.003" | ±0.003" | 4,000 psi (276 bar) | Natural | ● |
| 1/8" | 0.080" | ±0.003" | ±0.003" | 3,000 psi (207 bar) | Natural | ● |
